XingYu Bearings
| MODEL NO. | OUTER DIAMETER | DIAMETER TOLERANCE | LENGTH | DEPTH OF EFFECTIVE HARDENED LAYER | WEIGHT(kg/m) | |
| g6 | h6 | |||||
| SF6 | 6 |
-0.004 -0.012 |
0 -0.008 |
100-2000 | >0.8 | 0.22 |
| SF8 | 8 |
-0.005 -0.014 |
0 -0.009 |
100-2000 | 0.40 | |
| SF10 | 10 |
-0.005 -0.014 |
0 -0.009 |
100-2000 | >1.0 | 0.62 |
| SF12 | 12 |
-0.006 -0.017 |
0 -0.011 |
100-3000 | 0.89 | |
| SF13 | 13 | 100-3500 | 1.04 | |||
| SF16 | 16 | 100-4000 | >1.5 | 1.58 | ||
| SF20 | 20 |
-0.007 -0.020 |
0 -0.013 |
100-6000 | 2.47 | |
| SF25 | 25 | 3.85 | ||||
| SF30 | 30 | >2.0 | 5.55 | |||
| SF35 | 35 |
-0.009 -0.025 |
0 -0.016 |
7.55 | ||
| SF40 | 40 | >2.5 | 9.87 | |||
| SF50 | 50 | 15.4 | ||||
